Semi Automatic Black Bar Peeler
Semi automatic black bar peeling machine is one of main products of Yantai Haige Machine Tools Co., Ltd.The machine is equipped with automatic loading and unloading mechanism. Automatically input and output and automatically loading and unloading.
semi automatic black bar peeler
Yantai Haige Machine Tools Co., Ltd. was built in 1999, which specializes in producing steel finishing equipment, such as semi automatic black bar peeling machine, series JY Bar Straightening Machine, Abrasive Belt Grinder, Drawing Machine, Shot Blasting Machine, Centerless Grinding Machine, CNC skiving and Roller Burnishing Machine and Auxiliary Machine etc. We are also engaged in Continuous Hard Chrome Plating equipment and heat treatment equipment.
Based on more than 10 years experience in manufactur and design, our machines have been exported to Russia,Vietnam, India, Pakistan, Iran, South Korea, North Korea, Taiwan and other countries and regions. Our products and services have got more extensive customer recognition.
Semi automatic black bar peeling machine is one of main products of Yantai Haige Machine Tools Co., Ltd.
The main technical features of WXC130CA as follows:
1. It can process diameter size from 35 to 125mm
2. Feeding speed 1.0-5.0 m/min
3. Tolerance of finished goods h10
4. Surface roughness Ra less than 6.3 micron
5. Total capacity approximately 115kw
The machine is equipped with automatic loading and unloading mechanism. Automatically input and output and automatically loading and unloading. So it saves labor greatly and improves production capacity.
More pictures and technical parameters, please keep looking down.
|material requirement||diameter range (mm)||35＜dia＜135|
|material length (mm)||≥2800|
|diameter tolerance||according to GB 702-2004 second group|
|roundness(mm)||≤50% of diameter tolerance|
|finished product||diameter range(mm)||35≤dia≤130|
|diameter cutting depth(mm)||1.0~5.0|
|surface roughness (Ra)||≤6.3μm|
|feeding speed (m/min)||0.2~4.0|
|cutting head rotation rate per minute(rpm)||110~660|
|compressed air (prepared by user)||0.5~0.8MPa,1.8m3/min,0.8 m3 up air tank with two stage oil water separator and compressed air freezing type drying machine|
