CNC Auto Parts Peeling Machine

The machine is equipped with automatic loading and unloading mechanism. Automatically input and output and automatically loading and unloading, even it can be achieved online diameter measurement. So it saves labor greatly and improves production capacity.

Chat Now

Product Details

CNC auto parts peeling machine

Yantai Haige Machine Tools Co., Ltd. was built in 1999, which specializes in producing steel finishing equipment, such as CNC Auto Parts Peeling Machine, series JY Bar Straightening Machine, Abrasive Belt Grinder, Drawing Machine, Shot Blasting Machine, Centerless Grinding Machine, CNC skiving and Roller Burnishing Machine and Auxiliary Machine etc. We are also engaged in Continuous Hard Chrome Plating equipment and heat treatment equipment.

Based on more than 10 years experience in manufactur and design, our machines have been exported to Russia,Vietnam, India, Pakistan, Iran, South Korea, North Korea, Taiwan and other countries and regions.


CNC Auto Parts Peeling Machine is one of main products of Yantai Haige Machine Tools Co., Ltd.

Our bar peeling machine has been widely used in Auto parts industry.

WXC350S one of the most popular CNC type products.

The main technical features of WXC350S as follows:

1. It can process diameter size from 150mm to 350mm.

2. Feeding speed 0.2-2.0 m/min

3. the tolerance of finished goods can be reached h9

1. surface roughness of finished goods Ra not more than 3.2 micron.

The machine is equipped with automatic loading and unloading mechanism. Automatically input and output and automatically loading and unloading, even it can be achieved online diameter measurement. So it saves labor greatly and improves production capacity.

More pictures and technical parameters, please keep looking down.




SpecificationWXC350S
material requirementdiameter range (mm)150<dia<360
material length (mm)≥4500
yield strength(Mpa)≤1100
surface hardness≤HB320
straightness (mm/m)≤1.5
diameter toleranceaccording to GB 702-2004 second group
roundness(mm)≤50% of diameter tolerance
surface roughness(Ra)≤25~50μm
finished productdiameter range(mm)150≤dia≤350
diameter cutting depth(mm)1.0~10.0
diameter tolerance≤h9
surface roughness (Ra)≤3.2μm
feeding speed (m/min)0.2~2.0
cutting head rotation rate per minute(rpm)36~288
main motor(kw)200/250
total capacity(kw)265/315
compressed air (prepared by user)0.5~0.8MPa,1.8m3/min,0.8 m3 up air tank with two stage oil water separator and compressed air freezing type drying machine


Certificates



Customer



Exhibition



Packaging





Hot Tags: CNC auto parts peeling machine, manufacturers, high speed, high precision, high accuracy, high quality
