Semi Automatic Magnesium Rod Peeling Machine

Magnesium rod peeling machine is one of our main products, the machine is mainly used to wipe off the the surface crack, oxide layer and decarburized layer of the magnesium rod. Main machine consists of the bed, main bearings

Chat Now

Product Details

semi automatic magnesium rod peeling machine

Yantai Haige Machine Tools Co., Ltd. Was built in 1999, which specializes in producing steel finishing equipment, such as magnesium rod peeling machine, Series JY Bar Straightening Machine, Abrasive Belt Ginder, Drawing Machine, Shot Blasting Machine, Centerless Grinding Machine, CNC skiving and Roller Burnishing Machine and Auxiliary Machine etc. We also engage in continuous hard chrome plating equipment and heat treatment equipment.

Based on 15 years manufacture and design experience, our machines have been exported to Russia Vietnam, India, Pakistan, Iran, South Korea, North Korea, Taiwan and other countries and regions.


Magnesium rod peeling machine is one of our main products, the machine is mainly used to wipe off the the surface crack, oxide layer and decarburized layer of the magnesium rod. Main machine consists of the bed, main bearings, air/oil lubrication system,front-clamping pinch feeding and rear-clamping extracting, front guide and middle-rear guide system, main driving system etc.




model

WXC350S

material requirement

diameter range (mm)

150<dia<360

material length (mm)

≥4500

yield strength(Mpa)

≤1100

surface hardness

≤HB320

straightness (mm/m)

≤1.5

diameter tolerance

according to GB 702-2004 second group

roundness(mm)

≤50% of diameter tolerance

surface roughness(Ra)

≤25~50μm

finished product

diameter range(mm)

150≤dia≤350

diameter cutting depth(mm)

1.0~10.0

diameter tolerance

≤h9

surface roughness (Ra)

≤3.2μm

feeding speed (m/min)

0.2~2.0

cutting head rotation rate per minute(rpm)

36~288

main motor(kw)

200/250

total capacity(kw)

265/315

compressed air (prepared by user)

0.5~0.8MPa,1.8m3/min,0.8 m3 up air tank with two stage oil water separator and compressed air freezing type drying machine
