Semi Automatic Bearing Steel Wire Peeler

Semi automatic bearing steel wire peeler is one of our main products, mainly consists of two V groove clamping rollers, whose bearing seats are structural components .Two pairs of roller axle base are installed on the bearing seat, which can control separately. The axle base is cast steel installed on the slide bar.

Chat Now

Product Details

semi automatic bearing steel wire peeler

Yantai Haige Machine Tools Co., Ltd. Was built in 1999, which specializes in producing steel finishing equipment, such as wire peeler, Series JY Bar Straightening Machine, Abrasive Belt Grinder, Drawing Machine, Shot Blasting Machine, Centerless Grinding Machine, CNC skiving and Roller Burnishing Machine and Auxiliary Machine etc. We also engage in continuous hard chrome plating equipment and heat treatment equipment.

Based on 15 years manufacture and design experience, our machines have been exported to Russia, Vietnam, India, Pakistan, Iran, South Korea, North Korea, Taiwan and other countries and regions.



Semi automatic bearing steel wire peeler is one of our main products, mainly consists of two V groove clamping rollers, whose bearing seats are structural components .Two pairs of roller axle base are installed on the bearing seat, which can control separately. The axle base is cast steel installed on the slide bar. Through gear, rolling wheel is controlled by center spindle installed on the axle base, reaches purpose of automatically centering and clamping. The machine can keep working without any adjustment while diameter keeps changing.




modelWXC40C
material requirementdiameter range (mm)11<dia<40
material length (mm)≥1400
yield strength(Mpa)≤1100
surface hardness≤HB320
straightness (mm/m)≤1.5
diameter toleranceaccording to GB 702-2004 second group
roundness(mm)≤50% of diameter tolerance
surface roughness(Ra)≤25~50μm
finished productdiameter range(mm)10≤dia≤39
diameter cutting depth(mm)0.5~2.0
diameter tolerance≤h10
surface roughness (Ra)≤6.3μm
feeding speed (m/min)1.0~10.0
cutting head rotation rate per minute(rpm)900~2400
main motor(kw)45
total capacity(kw)65
compressed air (prepared by user)0.5~0.8MPa,1.8m3/min,0.8 m3 up air tank with two stage oil water separator and compressed air freezing type drying machine
