High Precision Copper Wire Peeler

copper wire peeler is one of our main products,To precisely locate after-peeled materials, trundle and clamp. Meanwhile prevent vibration, transmitting elements go into draw-out device. Transmit coolant, as well as cool turning tools and main spindle, clean chips.

Chat Now

Product Details

high precision copper wire peeler

Yantai Haige Machine Tools Co., Ltd. Was built in 1999, which specializes in producing steel finishing equipment, such as copper wire peeler, Series JY Bar Straightening Machine, Abrasive Belt Ginder, Drawing Machine, Shot Blasting Machine, Centerless Grinding Machine, CNC skiving and Roller Burnishing Machine and Auxiliary Machine etc. We also engage in continuous hard chrome plating equipment and heat treatment equipment.

Based on 15 years manufacture and design experience, our machines have been exported to Russia Vietnam, India, Pakistan, Iran, South Korea, North Korea, Taiwan and other countries and regions.



copper wire peeler is one of our main products,To precisely locate after-peeled materials, trundle and clamp. Meanwhile prevent vibration, transmitting elements go into draw-out device. Transmit coolant, as well as cool turning tools and main spindle, clean chips.

With hand godet transmitting pulling bar, two pairs( 6 in all) of rollers clamp after-peeled materials, going into operation as required. Pulling bar has single adjustment device, in order to adjust its precision, elastic device is designed, so that it can make compensation on the irregularity of materials. Coolant is expelled out from the special hole, sprays turning tools to make them cold. Meanwhile it can stop chip from entering. Back-flow coolant cools inner cover.



SpecificationWXC500C
material requirementdiameter range (mm)320<dia<510
material length (mm)≥4500
yield strength(Mpa)≤1100
surface hardness≤HB320
straightness (mm/m)≤1.5
diameter toleranceaccording to GB 702-2004 second group
roundness(mm)≤50% of diameter tolerance
surface roughness(Ra)≤25~50μm
finished productdiameter range(mm)315≤dia≤500
diameter cutting depth(mm)1.0~10.0
diameter tolerance≤h10
surface roughness (Ra)≤6.3μm
feeding speed (m/min)0.05~1.0
cutting head rotation rate per minute(rpm)20~160
main motor(kw)200
total capacity(kw)290
compressed air (prepared by user)0.5~0.8MPa,1.8m3/min,0.8 m3 up air tank with two stage oil water separator and compressed air freezing type drying machine
