CNC Spring Steel Wire Peeling Machine

spring steel wire peeling machine is one of our main products,Electric and air system is composed of electric power system and control system, which contains 1 power distribution cabinet and 1 operation button stations.

Chat Now

Product Details

CNC spring steel wire peeling machine

Yantai Haige Machine Tools Co., Ltd. Was built in 1999, which specializes in producing steel finishing equipment, such as spring steel wire peeling machine, Series JY Bar Straightening Machine, Abrasive Belt Ginder, Drawing Machine, Shot Blasting Machine, Centerless Grinding Machine, CNC skiving and Roller Burnishing Machine and Auxiliary Machine etc. We also engage in continuous hard chrome plating equipment and heat treatment equipment.

Based on 15 years manufacture and design experience, our machines have been exported to Russia Vietnam, India, Pakistan, Iran, South Korea, North Korea, Taiwan and other countries and regions.



spring steel wire peeling machine is one of our main products,Electric and air system is composed of electric power system and control system, which contains 1 power distribution cabinet and 1 operation button stations. It can realize electric and air control towards the front feeding in and and rear extracting system, cooling system, hydraulic system, chip conveyor and electric control of auxiliaries.
The main drive system adopts variable frequency stepless speed regulation, and the hydraulic cylinder is controlled by proportional valve.

The touch screen can display parameters such as spinning speed of cutting head and feeding speed.



model

WXC40S

material requirement

diameter range (mm)

11<dia<40

material length (mm)

≥1400

yield strength(Mpa)

≤1100

surface hardness

≤HB320

straightness (mm/m)

≤1.5

diameter tolerance

according to GB 702-2004 second group

roundness(mm)

≤50% of diameter tolerance

surface roughness(Ra)

≤25~50μm

finished product

diameter range(mm)

10≤dia≤39

diameter cutting depth(mm)

0.5~2.0

diameter tolerance

≤h9

surface roughness  (Ra)

≤3.2μm

feeding speed  (m/min)

1.0~12.0

cutting head rotation rate per minute(rpm)

900~2500

main motor(kw)

45

total capacity(kw)

65

compressed air (prepared by user)

0.5~0.8MPa,1.8m3/min,0.8 m3 up air tank with two stage oil water separator and compressed air freezing type drying machine
