Semi Automatic Machining Parts Peeler

RAW
MATERIALS

Diameter Range(mm)

Φ20~Φ85

Raw Material Length(mm)

≥2200

Tensile Strength (Mpa)

≤1100

Surface Hardness

≤HB320

Curvature(mm/m)

≤1.50①

Diameter Tolerance

According to GB 702-2004 second group

Roundness（mm）

≤50% of the diameter tolerance

Surface Roughness(Ra)

≤25~50μm

FINISHED
GOODS

Diameter Range

Φ19~Φ79

Unilateral Cutting Depth (mm）

0.25~1.0

Diameter Tolerance

≤IT9 (standard tolerance grade)

Surface Roughness(Ra)

≤6.3μm

Roundness（mm）

≤0.03

Feeding Cutting Speed（m/min）

1.0-10.0(for continuous chips and high strength
and hardness should reduce the speed)

Cutter Head Rotational Speed(rpm)

430~1200

Main Machine Motor Power(KW)

55

Auxiliary Machine Motor Power(KW)

5.5 X 2（Four Poles）

Main Machine Outline Dimensions
(Length*Width*Height) m

3.0m X 3.5m X 2.4m

Full Set Machine Outline Dimensions
(including auxiliary machine)
(Length*Width*Height) m

15.0m X 5.0m X 2.4m

Main Machine Weight
(including auxiliary weight) (T)

8.0 (11.5)

Total Capacity(KW)

75

Compressed Air Source
(user prepare by themselves）

0.5-0.8Mpa,1.8m3/min、0.8m3 gasholder、two-stage oil-water separator
and compressed air freezing drier.
