The WXC series of center-less lathe and JY series of straightening machines are high -level new equipment with independent intellectual property rights on the basis of absorbing and digesting foreign advanced technology, making adventurous innovation, and research&development take into consideration of actual situation of domestic companies. Our technology reaches the domestic advanced level in reliability and quality while keeps a relatively lower price, with its efficiency more several times than the conventional process. Our products are suitable to process different kinds of metal material, for instance, black metal material such as structural steel, alloy steel, spring steel, bearing steel,tool steel, copper and copper alloy, aluminum and aluminum alloy, magnesium alloy, titanium and titanium alloy and other non-ferrous metal materials. WXC series of centerless lathe is high-efficient specialized lathe to make a rough or fine machining to the surface of bar material such as slender shaft and other bars. It is able to not only get rid of the imperfection on the bar surface , de-carburized layer, crack etc, but also to guarantee relatively high accuracy. It is especially suitable to process extra long bar and bar with large machining allowance.
Send Inquiry

product-974-382



-1

Model

WXC255S

Raw

Materials

Diameter Range

Φ103-Φ255mm

Diameter Deviation

According to the Standard of Grade II GB702-86

Straightness

≤2mm/m

Tensile strength σb(Mpa)

≤1000MPa

Length Range

4.2m-6m(advanced configuration extracting trolley )

3.5m-6m(middle configuration extracting pressing roller)

Finished Products

Diameter Range

Φ100-Φ255

Dimension Accuracy

h9

Surface Roughness(Ra)

≤3.2

Main Technical Parameters

Diameter Cutting Amount

0.5-6mm

Cutter Head Rotation Speed

(variable frequency speed control of gear)

100-400r/min

Feeding Speed(variable frequency control)

0.2-3m/min(the rate need to be reduced when the material is more or less diameter,continuous chip,high hardness,deep cutting depth,bigger straightness)

Main Motor Power

200kW

Feeding Motor Power

11KW

Tool-adjusting Motor Power

3.5KW

Extracting Motor Power

2.2KW

Energy Consumption Parameters

Voltage

3×380V±10V

Frequency

50HZ±2%

Installed Capacity(reference)

250KW

Pneumatic Flow

1.5m3/min

Coolant Flow

170L/min

wxc255s2
