Milling Machine With High Quality For Pakistan

Blade Size :

Φ425

Feed Mode :

Servo Drive

Cut Range :

W: 2000-2300 x T: 20-100 mm

Forward and Backward Rate :

10 m / min

Cut Length :

≥20 mm

Feed Speed :

100-400 mm / min, Stepless Speed Change

Plate Length :

≤10000 mm

Main Shaft Precision :

0.005-0.01 mm

Clamp Mode :

Horizontal and Vertical

Cool Mode :

Oil and Mist Spray Cooling

Speed of Spindle :

50-120 r / min, Stepless Speed Change

Once Feed Length:

≤ 810 mm Recycled Feeding

Spindle Motor Power :

22 kW

Air Compression :

0.5-0.6 MPa

Cut Feed Motor Power :

4.7 kW

Chip Removal Mode :

Automatic

Feed Motor Power :

6 kW

Discharge Mode :

Automatic

Cut Side Roughness

≤Ra 6.3

Circulation :

Single, Multiple

Cut Side Perpendicularity :

≤0.35 mm / 100 mm

Machine Weight :

30 T

Cut Side Straightness : ≤0.5 mm / 2300 mm

≤0.5 mm / 2300 mm

Machine Dimension :

11000 x 7000 x 2700 mm

Cut Tolerance :

±1 mm
