China Metallic Processing Machinery Round Steel Bar Peeling Lathe

Name: Semi Automatic Bright Bar Peeler - China Semi Automatic Bright Bar Peeler Manufacturers - Haige
Brand: Haige
SKU: 43697782

Compared CNC bright bar peeler, semi automatic bright bar peeler has cheap price and meet user need. Semi automatic surface roughness can achieve h10 diameter tolerance and roughness between 6.3 μm-3.2μm.

Send Inquiry

semi automatic bright bar peeler

Yantai Haige Machine Tools Co.,Ltd is China biggest and best CNC bright bar peeler and semi automatic bright bar peeler manufacturer . Compared CNC bright bar peeler, semi automatic bright bar peeler has cheap price and meet user need. Semi automatic surface roughness can achieve h10 diameter tolerance and roughness between 6.3 μm-3.2μm. Semi automatic bright bar peeler needs operator has high skill on machine adjusting and basic knowledge.



Main Technical Parameters--WXC350C

Specification		WXC350C
RAW MATERIALS	Diameter Range(mm)	Φ150~Φ355
	Raw Material Length(mm)	≥4500
	Tensile Strength (Mpa)	≤1100
	Surface Hardness	≤HB320
	Curvature(mm/m)	≤1.50
	Diameter Tolerance	According to GB 702-2004 second group
	Roundness（mm）	≤50% of the diameter tolerance
	Surface Roughness(Ra)	≤25~50μm
FINISHED GOODS	Diameter Range	Φ149~Φ355
	Unilateral Cutting Depth (mm）	0.25~1.0
	Diameter Tolerance	≤IT9 (standard tolerance grade)
	Surface Roughness(Ra)	≤6.3μm
	Roundness（mm）	≤0.03
Feeding Cutting Speed（m/min）	0.1-1.0(for continuous chips and high strength and hardness should reduce the speed)
Cutter Head Rotational Speed(rpm)	430~1200
Main Machine Motor Power(KW)	55
Auxiliary Machine Motor Power(KW)	5.5 X 2（Four Poles）
Main Machine Outline Dimensions (LengthWidthHeight) m	8m * 5m * 5.5m
Full Set Machine Outline Dimensions (including auxiliary machine) (LengthWidthHeight) m	22m X 8m X 8.5m
Main Machine Weight (including auxiliary weight) (T)	60t(only for your reference)
Total Capacity(KW)	400kw
Compressed Air Source (user prepare by themselves）	0.5-0.8Mpa,1.8m3/min、0.8m3 gasholder、two-stage oil-water separator and compressed air freezing drier.
