Hot Sale China Haige Crushing And Briquetting Machine

Name: China Hot Sale China Haige Crushing And Briquetting Machine Manufacturers - Haige
Brand: Haige
SKU: 175437988

According to the market needs, our company through continuous technical innovation, the company has developed an independent intellectual property right of automatic chip drying machine, high efficiency and low energy consumption vertical chip crushing machine,full automatic horizontal hydraulic block compressing machine, chip box lifting pouring machine and magnetic selection, wind separation, vibration sieve and other related equipment related to the chip processing. Relying on the international advanced technology, combined with the actual domestic production, we have successfully provided users with an objective number of intelligent chip processing systems, and exported to Russia, Malaysia, Taiwan, Sweden and other countries and regions, the provided products are at the market leading level.Become a leading equipment manufacturer and system supplier in the field of chip processing. The company has currently passed the ISO14001:2015 environmental management system certification and ISO9001:2015 quality management system certification.In this historical period of the new industrial revolution, facing the strategic opportunities of intelligent manufacturing 2025, we believe that our high-quality products, first-class services and comprehensive solutions program will be able to help our users achieve their goals and value, can help our enterprise industrial upgrading and green manufacturing, reduce production costs and protect our environment.

Send Inquiry

1.Product Introduction

Relying on the international advanced technology, combined with the actual domestic production, we have successfully provided users with an objective number of intelligent chip processing systems, and exported to Russia, Malaysia, Taiwan, Sweden and other countries and regions, the provided products are at the market leading level.Become a leading equipment manufacturer and system supplier in the field of chip processing.

The company has currently passed the ISO14001:2015 environmental management system certification and ISO9001:2015 quality management system certification.In this historical period of the new industrial revolution, facing the strategic opportunities of intelligent manufacturing 2025, we believe that our high-quality products, first-class services and comprehensive solutions program will be able to help our users achieve their goals and value, can help our enterprise industrial upgrading and green manufacturing, reduce production costs and protect our environment.

2.Main Parameters

project	specifications
Total power of equipment	22kw
working voltage	50HZ/380V
Block pressing ability	600Kg/h
system pressure	25Mpa
Main oil cylinder diameter	Φ350mm
Main piston rod diamete	Φ160mm
Working stroke	300mm
Body shape dimension	2300mmX2200mmX 1950mm
Material outlet height	1000mm
Block pressing specification	Φ 110mm
Block pressing frequency	3-4block /min
Cylinder pressing method	Double holes and double exits
Block pressing density	4. 5-5. 5g/cm3

3.Design Parameter Equirements

Chip material: steel: 20CrMnTi, 20MnCr5,30MnVS6

Processing method: lathe, milling machine, processing center and other mechanical processing

Chip form: rolling chip, fine chip

Processing type: wet processing

Crushing granularity: about 3-5 cm;

Production requirements: 600KG / h, 8 h / day, 21 days / month, 12 months / year

Water content after drying: <5% (According to the quality ratio)

Safety protection: the pit is equipped with a safety barrier, the equipment has a complete safety protection device, the safety protection device opens, the equipment will automatically shutdown and alar

4.Main Devices

Device name	model
Pit crushing machine	GR-TFS0230
Lifting conveyor	GRLB1-400
Temporary liquid tank and water pump	GRLBYX
Metal drying machine	GRTSG0240
Dried chip conveyor	GRLB2-400
Metal block pressing machine	GRTPB2-45/110
guardrail and steel grating	GRC
Electric control system	PLC siemens

5.Packing

we have much experience in exporting transportation packaging. Taking multi protection measures:

The first layer
wrapping with foam film and stretch film for the special components, in order to avoid moisture.

Second layer
inside of plywood box, adopting small square plywood block and strapping belt to fix.

Third layer
the machine itself has screw fixing holes, so it can be tightly fixed on the bottom of the plywood box through screw and nut.

Fourth layer
in a container, by compact layout, reducing the gap between boxes to avoid shaking. At the same time, reinforcing between the bottom of the container and plywood boxes once again, furthermore using hanging steel wire protection.

002

003

001

6.Company Profile

Yantai Haige International Trading Co.,Ltd.,is a joint-stock enterprise engaged in exporting products such as machines,pumps and parts etc. produced in China to the markets abroad,which is located in Laishan district,Yantai City,Shandong Province,China. Our company is based on the manufacturing plant-Yantai Haige machine tools Co.,Ltd and Yantai Hangjian Refined Special Steel Equipment Co.,Ltd. which focus on manufacturing many kinds of metal finishing equipment. Area of the factory is about 10000 square meter. There are one hundred and sixty staffs working in the factory,includes 14 staffs focusing on R&D.

company

company1

We have exported various products which mostly are machines and machine parts to many countries.We can provide timely oversea service. We are the exclusive agent of Yantai Volm Vacuum Technology Co.,Ltd.,which focus on manufacturing various of vacuum pumps,we represent their business in international markets.Also we are appointed to be the sole sales agent of Shandong Gexin machinery manufacturing Co.,Ltd. for their Rotational Moulding products and machine. We focus on the the quality of the products we sell,We welcome you to our plant and hope to have the pleasure of providing you the perfect products and best services.
