The WXC series of center-less lathe and JY series of straightening machines are high -level new equipment with independent intellectual property rights on the basis of absorbing and digesting foreign advanced technology, making adventurous innovation, and research&development take into consideration of actual situation of domestic companies. Our technology reaches the domestic advanced level in reliability and quality while keeps a relatively lower price, with its efficiency more several times than the conventional process. Our products are suitable to process different kinds of metal material, for instance, black metal material such as structural steel, alloy steel, spring steel, bearing steel,tool steel, copper and copper alloy, aluminum and aluminum alloy, magnesium alloy, titanium and titanium alloy and other non-ferrous metal materials. WXC series of centerless lathe is high-efficient specialized lathe to make a rough or fine machining to the surface of bar material such as slender shaft and other bars. It is able to not only get rid of the imperfection on the bar surface , de-carburized layer, crack etc, but also to guarantee relatively high accuracy. It is especially suitable to process extra long bar and bar with large machining allowance.
Send Inquiry

product-974-382



Specification&composition

Specification

WXC60C(semi-auto)

RAW
MATERIALS

Diameter Range(mm)

Φ14~Φ60

Raw Material Length(mm)

≥2200

Tensile Strength (Mpa)

≤1100

Surface Hardness

≤HB320

Curvature(mm/m)

≤1.50

Diameter Tolerance

According to GB 702-2004 second group

Roundness(mm)

≤50% of the diameter tolerance

Surface Roughness(Ra)

≤25~50μm

FINISHED
GOODS

Diameter Range

Φ13.5~Φ59

Unilateral Cutting Depth (mm)

0.5~1.0

Diameter Tolerance

≤IT10 (standard tolerance grade)

Surface Roughness(Ra)

≤6.3μm

Roundness(mm)

≤0.03

Feeding Cutting Speed(m/min)

1.0-8.0(for continuous chips and high strength

and hardness should reduce the speed)

Cutter Head Rotational Speed(rpm)

440~1300

Main Machine Motor Power(KW)

45

Auxiliary Machine Motor Power(KW)

4.0X 2(Four Poles)

Main Machine Outline Dimensions

(Length*Width*Height) m

3.0m X 2.5m X 2.0m

Full Set Machine Outline Dimensions

(including auxiliary machine)

(Length*Width*Height) m

13.0X2.5X2.4

Main Machine Weight
(including auxiliary weight) (T)

5.0(8.0)

Total Capacity(KW)

75

Compressed Air Source

(user prepare by themselves)

0.5-0.8Mpa,1.8m3/min,0.8m3 gasholder,two-stage oil-water separator

and compressed air freezing drier.



Processing procedure

loadingrack/on-linemechanism > Pneumaticautomatichandlingarm > loadingrollers > feedingdevice > frontguidedevice >mainspindledevice > middlerearguidedevice  >  trolleydevice  >  outputdevice  >  unloading rollers >  pneumaticautomatichandlingarm  >  unloadingrack/on-line mechanism
