High Quality WXC40S CNC TYPE Centerless Lathe

The WXC series of center-less lathe and JY series of straightening machines are high -level new equipment with independent intellectual property rights on the basis of absorbing and digesting foreign advanced technology, making adventurous innovation, and research&development take into consideration of actual situation of domestic companies. Our technology reaches the domestic advanced level in reliability and quality while keeps a relatively lower price, with its efficiency more several times than the conventional process. Our products are suitable to process different kinds of metal material, for instance, black metal material such as structural steel, alloy steel, spring steel, bearing steel,tool steel, copper and copper alloy, aluminum and aluminum alloy, magnesium alloy, titanium and titanium alloy and other non-ferrous metal materials. WXC series of centerless lathe is high-efficient specialized lathe to make a rough or fine machining to the surface of bar material such as slender shaft and other bars. It is able to not only get rid of the imperfection on the bar surface , de-carburized layer, crack etc, but also to guarantee relatively high accuracy. It is especially suitable to process extra long bar and bar with large machining allowance.

Send Inquiry

product-974-382

The main spindle device driven by the main transmission through the synchronous belt enable the cutter head which is equipped with four adjustable cutters to rotate with high precision and speed. Material bar is conveyed in through the front feeding clamping device which gives the bar the linear forwarding motion. Front guide makes centralize the bar, then the cutting head begins peeling process. After peeling, the bar enters to the middle and rear guide part to further centralize.At last the extracting components convey the finished bar to unloading rollers, above all, the whole high speed peeling process is finished.

When the bar is peeling almost to the end, clamping trolley automatically fastens it, and synchronously extracts it with front guide component, which guarantees that there is no obvious dent on the bar surface after peeling.

Main parameters

Model		WXC40S
Material	Diameter Range(mm)	Φ9~Φ40X1500~unlimited
	Yield Strength σ_b(Mpa)	≤1000
	Surface Hardness	≤HB320
	Original Curvature Curvature(mm/m)	≤1 .5^①
	Diameter Tolerance	According to GB 702-88,Grade 2
	Roundness	≤50% of the diameter tolerance
	Surface Roughness(Ra)	≤25～50mm
After Peeling	Diameter Range(mm)	Φ8~Φ39
	unilateral Cutting Depth(mm)	0.2~1
	Diameter Tolerance	≤h10(standard tolerance grades)
	Surface roughness(Ra)	≤6.3μm
	Roundness	≤0.03
Feeding rate(continuous variable transmission m/min)		1.0-12(The processing rate needs to be slow down when it works with Continuous chip, high strength, high hardness, deeper turning, large and small diameter material.)
