WXC80C Semi-automatic TYPE Centerless Lathe
The WXC series of center-less lathe and JY series of straightening machines are high -level new equipment with independent intellectual property rights on the basis of absorbing and digesting foreign advanced technology, making adventurous innovation, and research&development take into consideration of actual situation of domestic companies. Our technology reaches the domestic advanced level in reliability and quality while keeps a relatively lower price, with its efficiency more several times than the conventional process.
Our products are suitable to process different kinds of metal material, for instance, black metal material such as structural steel, alloy steel, spring steel, bearing steel,tool steel, copper and copper alloy, aluminum and aluminum alloy, magnesium alloy, titanium and titanium alloy and other non-ferrous metal materials.
WXC series of centerless lathe is high-efficient specialized lathe to make a rough or fine machining to the surface of bar material such as slender shaft and other bars. It is able to not only get rid of the imperfection on the bar surface , de-carburized layer, crack etc, but also to guarantee relatively high accuracy. It is especially suitable to process extra long bar and bar with large machining allowance.
Send Inquiry
Product descripation:
Our products are suitable to process different kinds of metal material, for instance, black metal material such as structural steel, alloy steel, spring steel, bearing steel,tool steel, copper and copper alloy, aluminum and aluminum alloy, magnesium alloy, titanium and titanium alloy and other non-ferrous metal materials.
The spindle is driven by the main drive through the synchronous belt drive gear box, then drives the cutter head which is equipped with four adjustable cutters to produce the precision and high speed rotation movement. Rod is feed in through the front feeding clamping, and is given a linear and feeding motion. Front guide makes the central location to the bar, and after that, the cutting heads begin to peel the bar on the surface. After peeling, the bar enters to the middle and rear guide part to experiences another central location. The extracting components deliver the after-peeling bar to unloading rollers. That is the brief introduction of the whole production process.
