Yantai Haige WXC60Y Black Bar Peeling Lathe

Name: China High Speed Yantai Haige WXC60Y Black Bar Peeling Lathe Manufacturers - High Quality - Haige
Brand: Haige
SKU: 156945987

Quick Details Place of Origin: Shandong, China Brand Name: haige Condition: New Machine Type: Bar peeling machine Video outgoing-inspection: Provided Machinery Test Report: Provided Marketing Type: Ordinary Product Warranty of core components: 1 Year Core Components: PLC, Bearing, Gearbox, Motor, Gear Warranty: 1 Year After-sales Service Provided: Online support, Field installation, commissioning and training, Field maintenance and repair service, Video technical support Key Selling Points: Easy to Operate After Warranty Service: Video technical support, Online support Local Service Location: None Applicable Industries: Manufacturing Plant, Other Showroom Location: None After sales service: engineers are available to supervise on site Color: customized applications: automobile sector Automatic Grade: Semi-automatic warranty: 12months standard: ISO9001 material length: ≥2800 yield strength: ≤1100 surface hardness: ≤HB320 straightness: ≤1.5

Send Inquiry

Product Description

Description:

Quality: Our company regards quality as life. We have already passed ISO9001 certification, and strictly implement the ISO9001 international quality management system. We keep improving quality in order to let customers buy with comfort and use with satisfaction.
Our company can also make specified equipment according to customers’ requirement.

Our service:
1. Free quality guarantee period for 12 months, except for wearing parts.
 2. Free provide long-term technical support
 3. Free train buyer’s operator in seller’s factory
 4. Fast response service within 24 hours
 5.Our engineers can offer overseas service, including guiding installation, commissioning, training, etc, if our customer needs.

Specification

model		WXC60Y
material requirement	diameter range (mm)	Φ16~Φ62
	material length (mm)	3000~6000(Among them, 2.5m - 3.1m short material needs to slow down)
	yield strength(Mpa)	≤1100
	surface hardness	≤HB320
	straightness (mm/m)	≤1.5
	diameter tolerance	According to GB 702-2004,Grade2
	roundness(mm)	≤50% of diameter tolerance
	surface roughness(Ra)	≤25～50μm
finished product	diameter range(mm)	Φ15~Φ60
	diameter cutting depth(mm)	0.5~2
	diameter tolerance	≤h10(standard tolerance grade)
	surface roughness (Ra)	≤6.3μm
feeding speed (m/min)		2.0~9.0
Cutting Head Rotational Speed（rpm）（r/min）		430~1300
main motor(kw）		45
total capacity（kw）		65
compressed air (prepared by user)		0.5~0.8MPa、1.8m3/min、0.8 m3 and above air tank、 2 grade oil&water separator
