Product descripation:
HGLG50HSL continuous pilger mill is a brand new design and manufacture of our company.It is used to roll precision thin-walled pipes of various carbon steels, alloy steels, stainless steels, non-ferrous metals, rare metals and precision alloys with OD φ6-φ18, wall thickness of 0.3-4mm in cold state.
The machine adopts two-roll ring-shaped roller, with large reduction of OD and WT, long working stroke and other characteristics. At the same time, the AC servo motor is used to control the rotation and feeding, and the automatic high-speed work without stopping the machine increases the output and reduces the labor intensity of the workers.
|
Name |
Unit |
HGLG-50-HLLLS |
|
External diameter of tube blank |
mm |
Φ25-Φ65 |
|
Thickness of tube blank |
mm |
2-16 |
|
Length of tube blank |
m |
2-6 |
|
External diameter of finished-tube |
mm |
Φ25-Φ40 |
|
Common difference of external diameter of tube blank |
m |
±0.1 |
|
Common difference of thickness of tube blank |
m |
±0,4 |
|
bending of tube blank |
mm/m |
≤2 |
|
Thickness of finished-tube |
mm |
0.5-15 |
|
Length of finished tube |
m |
≤15 |
|
Common difference of external diameter of finished-tube |
% |
±0.065 |
|
Common difference of thickness of finished-tube |
% |
70% |
|
Elongation coefficient |
≤3.5 |
|
|
Feed quantity |
mm /time |
1-8 |
|
Total rotation angle |
度 |
33-75 |
|
Work mode of rolling mill |
Continuous feeding of close-top roll housing |
|
|
Rotary feeding mechanism and working mode |
Double feeding and double return and single feeding and single return are available |
|
|
Pitch circle of roller driving gear |
mm |
|
|
Roller hole form: |
Circular groove |
|
|
Roller diameter |
mm |
Φ350-Φ190×Φ150 |
|
Working length of hole |
||
|
Reciprocating speed of roll housing |
Time / min |
50-220 |
|
Run-length of roll housing |
mm |
763 |
|
Main power |
kw |
132 |
|
Maximum force of rolling mill |
t |
260 |
|
Flow of technological lubrication |
L/min |
63 |
Product display:
