Product Introduction YM80SA belt polishing machine is specially designed for the bars with high requirements for surface roughness. The main technical parameters and functions are as follows. The spindle of this machine is hollow-core structure.
|
Main technical parameters |
Belt speed(Variable speed) |
0～20M/S |
|
Belt disc rotating speed |
80r/min(48-100r) |
|
|
Feeding speed |
≤6m/min(The larger the diameter, the slower the speed) |
|
|
Main machine power |
22kW |
|
|
Feeding motor power |
3KW 2 sets(Variable speed) |
|
|
Roll way motor power |
1.5KW 2 sets |
|
|
Lifting motor power |
1.5KW 2 sets |
|
|
Tape motor power |
2.2KW |
|
|
Running noise |
≤75dB |
|
|
Cleaning fluid flow |
200L/min |
