Model |
WXC255S |
|
|
Raw Materials |
Diameter Range |
Φ91-Φ250mm |
|
Diameter Deviation |
According to the Standard of Grade II GB702-86 |
|
|
Straightness |
≤2mm/m |
|
|
Length Range |
4.2m-6m(it can be prolonged according to the actual requirements) |
|
|
Finished Products |
Diameter Range |
Φ90-Φ248 |
|
Dimension Accuracy |
h9 |
|
|
Surface Roughness(Ra) |
≤3.2 |
|
|
Main Technical Parameters |
Diameter Cutting Amount |
0.5-6mm |
|
Cutter Head Rotation Speed (variable frequency speed control of gear) |
70-400r/min |
|
|
Feeding Speed(variable frequency control) |
0.2-3m/min |
|
|
Main Motor Power |
200kW |
|
|
Feeding Motor Power |
15KW |
|
|
Tool-adjusting Motor Power |
4KW |
|
|
Extracting Motor Power |
2.2KW |
|
|
Energy Consumption Parameters |
Voltage |
3×380V±10% |
|
Frequency |
50HZ±2% |
|
|
Installed Capacity(reference) |
250KW |
|
|
Pneumatic Flow |
1m3/min |
|
|
Coolant Flow |
170L/min |
|
Main Parts Technical Parameters:
|
Loading Racks |
Outline Dimensions (Length*Width*Height) (for your reference) |
6000×2000×1350 |
|
Numbers of Material-handling Arms |
6 pcs |
|
|
Loading Roller Table |
Center Height(for your reference) |
1230 |
|
Adjusting Range |
180 |
|
|
Numbers of Rollers |
6 pcs |
|
|
Lifting Motor |
1.5KW AC 1 set |
|
|
Feeding Motor |
2.2KW AC 1 set |
|
|
Unloading Roller Table |
Center Height(for your reference) |
1230 |
|
Adjusting Range |
180 |
|
|
Numbers of Rollers |
11 pcs |
|
|
Lifting Motor |
1.5KW AC 1 set |
|
|
Feeding Motor |
2.2KW AC 1 set |
|
|
Feeding Device |
Feeding Motor |
15KW |
|
Speed-adjusting Method |
AC Frequency |
|
|
Form of Transfer Case |
one in four out |
|
|
Feeding Speed |
0.2-3m/min Variable Speed Regulation |
|
|
Diameter of Pinch Roller |
φ300mm |
|
|
Diameter of Hydraulic Cylinder |
Φ125X2 sets |
|
|
System Pressure |
14MPa |
|
|
Front-guide Device |
Clamping Cylinder |
φ63 1pcs |
|
Flipping Cylinder |
φ100 1pcs |
|
|
System Pressure |
14MPa |
|
|
Main Spindle Device |
Main Motor |
200KW AC 1 set Variable Speed Regulation |
|
Speed-adjusting Method |
AC frequency conversion |
|
|
Main Spindle Rotation Speed |
70-400r/min Gear Variable-speed frequency conversion |
|
|
Transmission Mode |
Direct Link |
|
|
Numbers of Cutter Head |
1 |
|
|
Tool-adjusting Method |
Servo Electric,Synchronous,Automatic Centering |
|
|
Servo Motor |
4KW 1 set |
|
Middle&Rear Guide Device&Extracting carriage(extractingtrolley) device |
Worm Gear Modulus |
m=8 |
|
Worm Number |
Z=1 |
|
|
Pulling-out Stroke |
2000mm |
|
|
System Pressure(Hydraulic) |
14MPa |
|
|
Unloading Device |
Transmission Motor |
2.2KW AC Infinitely Variable Speed Regulation 1 set |
|
Speed-adjusting Method |
AC Frequency Conversion |
|
|
Clamping Cylinder |
φ160 1 |
|
|
System Pressure |
14MPa |
|
|
Chip Conveyor Device |
Chip Conveyor Motor |
0.75KW AC 1 set |
|
Unloading Racks&Material- collecting Device |
Outline Dimensions (Length*Width*Height) (for your reference) |
6000×2000×1350 |
|
Numbers of Material-handling Arms |
6 pcs |
|
|
Single Bundle Weight |
10000Kg |
|
|
Electrical System |
Main Power |
Three Phase Four Wire |
|
Voltage |
380V±10% AC |
|
|
Frequency |
50HZ±2% |
|
|
Control Power |
Single Phase AC220V DC24V |
|
|
Hydraulic System |
System Pressure |
14MPa |
|
Motor |
15KW 1 set |
|
|
Flow |
58L/min |
|
|
Cooling System |
Coolant Medium |
Emulsion |
|
Motor |
0.45KW |
|
|
Flow |
200L/min |
