JZ7G160 7-roll Straightening Machine

The WXC series of center-less lathe and JY series of straightening machines are high -level new equipment with independent intellectual property rights on the basis of absorbing and digesting foreign advanced technology, making adventurous innovation, and research&development take into consideration of actual situation of domestic companies. Our technology reaches the domestic advanced level in reliability and quality while keeps a relatively lower price, with its efficiency more several times than the conventional process. Our products are suitable to process different kinds of metal material, for instance, black metal material such as structural steel, alloy steel, spring steel, bearing steel,tool steel, copper and copper alloy, aluminum and aluminum alloy, magnesium alloy, titanium and titanium alloy and other non-ferrous metal materials. WXC series of centerless lathe is high-efficient specialized lathe to make a rough or fine machining to the surface of bar material such as slender shaft and other bars. It is able to not only get rid of the imperfection on the bar surface , de-carburized layer, crack etc, but also to guarantee relatively high accuracy. It is especially suitable to process extra long bar and bar with large machining allowance.

Send Inquiry

JZ7G160 7-roll Straightening Machine

Equipment Composition and Function

The equipment includes: Loading system, straightening machine body, extract device and unloading collection system, and is equipped with the corresponding electronic control, lubrication and cooling system.

Working Process Description

1,Crane Loading: Carry the bar material up to loading rack using driving crane. Finer materials and large straightness material need to be manually paved, so as not to cross between materials, affecting automatic feeding.

2,Pneumatic material kick-off Arm：Pneumatic material kick-off arm automatically moves the bar to the loading roller.(Manual feeding is required for materials with smaller diameter and larger straightness).

3,Loading Roller: It is used for sending the bar to straightener.

4,Main Body of Straightener: The straightener adopts alternately symmetric bending and straightening theory. Through the craft such as inclined arrangement of roller, special designed roller shape, distance between rollers and the fitting of guide distance, the bar experiences multiple alternately symmetric bending. And multiple elastic plastic bending deformation happens on the bar surface when it moves forward in the straightening process, which guarantees the bar straightening effect.

5,Extraction device: by pneumatic clamping roller will extract out the workpiece from the straightening machine, sent to the receiving box.

6,collecting device: The material colleting trough is pneumatically opened, and the workpiece roll-in the material colleting trough.
